AsteRx SBi3 Pro+
AsteRx SBi3 Pro+

Septentrio AsteRx SBi3 Pro+

6,190.00$

The AsteRx SBi3 Pro+ is a rugged, IP68-rated GNSS/INS receiver engineered for centimeter-level, IMU-enhanced positioning and 3D orientation. Designed for sensor fusion applications, it provides full access to raw GNSS and IMU data for advanced system integration. Supporting single or dual-antenna configurations, it delivers accurate heading, pitch, and roll measurements in real time. Equipped with AIM+ anti-jamming and anti-spoofing technology and multi-constellation, multi-frequency RTK tracking, the AsteRx SBi3 Pro+ ensures reliable performance even in demanding environments. Its compact, weatherproof housing, intuitive Web Interface, and automatic lever arm optimization enable fast, seamless integration across machine control, robotics, and industrial applications.

Category:

Description

AsteRx SBi3 Pro+ – Compact GNSS/INS Receiver for Precision Positioning and Orientation

Reliable Centimeter-Level Positioning with 3D Orientation

The AsteRx SBi3 Pro+ is a high-performance, multi-frequency GNSS/INS receiver designed to deliver centimeter-level positioning accuracy and full 3D orientation in the most challenging environments.
With its integrated inertial sensor, the receiver provides precise heading, pitch, and roll measurements, as well as dead-reckoning capabilities, ensuring continuous navigation even when GNSS signals are temporarily lost.

Versatile and Ready for Any Integration

Engineered for flexibility, the AsteRx SBi3 Pro+ is the most adaptable boxed GNSS/INS solution in its class. It offers full access to raw GNSS and INS data, allowing developers to fine-tune system performance for specialized applications.
The receiver supports multiple antenna configurations, enabling superior accuracy and orientation capability across diverse platforms.

Optimized for Machine Control and Robotics

Designed for rapid system integration, the AsteRx SBi3 Pro+ is ideal for machine control, autonomous ground vehicles, and robotic systems that demand precise, real-time positioning under any condition.
Its compact, rugged housing ensures long-term reliability in industrial environments while maintaining low latency and high data update rates for dynamic applications.

Technical Specifications – AsteRx SBi3 Pro+ GNSS/INS Receiver

GNSS Technology

  • Hardware Channels: 554

  • Supported Constellations:

    • GPS: L1 C/A, L1PY, L2C, L2P, L5

    • GLONASS: L1 C/A, L2 C/A

    • BeiDou: B1I, B2I, B3I

    • Galileo: E1, E5a, E5b, E5 AltBOC

    • QZSS: L1 C/A, L2C, L5

Septentrio GNSS+ Technologies

  • AIM+ – Advanced anti-jamming, anti-spoofing, and interference monitoring

  • FUSE+ – Fusion of RTK positioning with inertial sensor data for continuous accuracy

  • APME+ – Advanced multipath mitigation for improved precision in reflective environments

  • LOCK+ – Superior tracking performance under mechanical vibration or shock

  • IONO+ – Ionospheric scintillation mitigation for reliable GNSS signal tracking

  • RAIM+ – Receiver Autonomous Integrity Monitoring for enhanced positioning reliability

Interfaces

  • High-speed Serial Ports (RS232): 3

  • Ethernet Port (TCP/IP, UDP, LAN 10/100 Mbps): 1

  • Power over Ethernet (PoE): Supported

  • High-speed / Full-speed USB Device Port: 1

  • FTP Server: Built-in

  • Internal Memory: 16 GB

Integrated Position Accuracy

  • Standalone (Horizontal): 1.2 m

  • Standalone (Vertical): 1.9 m

  • SBAS (Horizontal): 0.6 m

  • SBAS (Vertical): 0.8 m
